Orion Star™ A214 pH/ISE Benchtop Multiparameter Meter, Thermo Orion
or call us at 1-800-727-0467
- Anyone can use this meter with its plain language screen prompts, soft keys that update for easy selection and a multilanguage interface that supports English, Spanish, French, Italian, German and Chinese
- Don't miss a reading – AUTO-READ* locks in the stable reading on your screen, ready indicator alerts when readings are stable and timed reading gathers data in specific time intervals
- Up to five point pH calibration with automatic recognition for USA/NIST and DIN buffers
- Whether you use ISE infrequently or have multiple samples every day – up to five point ISE calibration with advanced features such as timed end point, linear point-to-point, non-linear selectable auto-blank and low-concentration range stability
- Fix errors without a complete recalibration with the calibration editing function
- Non-volatile memory holds up to 2000 data points with time and date stamp
- Easily transfer data and keep meter software up-to-date with the USB and RS232 ports and complimentary data analysis software
- Mix samples without a stir plate with direct control of the Orion Star stirrer probe (096019, sold separately)
- Included electrode arm and newly-designed probe holder make it easier to maintain and place probes into samples
- Works with almost every AC power source with the included universal power adapter, or use four AA batteries (sold separately) to run the meter on DC power
- IP54-rated housing handles splashes and is wall-mountable if table space is a problem
- Three year meter replacement warranty
Certifications: CE, TUV, FCC Class A limits
| Manufacturer | N/A |
|---|---|
| Promo Text | N/A |
Specifications | |
pH Mode | |
Range | -2.000 to 20.000 |
Resolution | 0.1, 0.01, 0.001 |
Relative Accuracy | ±0.002 |
Calibration Points | up to 5 |
ISE Mode | |
Range | 0 to 19999 in ppm, M, mg/L, %, ppb or unitless |
Resolution | up to 3 significant digits |
Relative Accuracy | ±0.2 mV or ±0.5% of reading, whichever is greater |
Calibration Points | up to 5; Calibration point editing, timed and point, linear point to point, non-linear selectable auto-blank, low concentration range stability |
mV Mode | |
Range | ±2000.0 |
Resolution | 0.1 |
Relative Accuracy | ±0.2mV or ±0.05% of reading whichever is greater |
Calibration Points | 1 |
Temperature Mode | |
Range | 23° to 221°F (-5° to 105°C) |
Resolution | 0.1 |
Relative Accuracy | ±0.1 |
Inputs/Outputs | |
Inputs | BNC, reference pin, 8-pin mini-DIN, stirrer port |
Data Management | 2000 points with date/time stamp |
Output | RS-232, USB |
Display | Graphic LCD; simultaneous display of measurement, temperature, date/time, sample ID, user ID and more |
Power Supply | Universal AC line voltage or optional four "AA" batteries |
Environmental Operating Conditions | |
Ambient Operating Temperature | 5 to 85% noncondensing |
