Stirrer Motor for Freezing Point Apparatus, Koehler

Redesigned constant temperature bath for freezing point determinations on fuel samples at temperatures as low as –100°F (–73°C). Accommodates K29700 Freezing Point Apparatus and accessory stirrer. Microprocessor PID circuitry provides precise, reliable temperature control within ASTM specified tolerances. Simple push button controls and dual digital displays permit easy setting and monitoring of bath temperature. Bath medium is contained in a clear, evacuated Dewar flask, and glare-free fluorescent backlighting provides excellent visibility when working with the freezing point samples. Air-cooled hermetic compressors provide efficient operation with the use of CFC-free refrigerants. Temperature control uniformity is assured by means of a motorized stirrer which provides complete circulation without turbulence. Cabinet construction is polyester-epoxy finished steel with a chemical-resistant composite top surface. Working (top) surface includes port and mounting plate for K29700 Freezing Point Apparatus and accessory stirrer. Bath rests on adjustable leveling feet.

Specifications
Conforms to: ASTM D2386; IP 16; ISO 3013; DIN 51421; FTM 791-1411; NF M 07-048

Temperature Range: Ambient to –100°F (–73°C)

Temperature Control Accuracy and Uniformity: Exceeds ASTM requirements throughout the operating range

Display: 0.1°C/°F resolution

Electricial Requirements:
This item is for 115V, 60 Hz, Single Phase, 18.3A
